Name: Beaker & Wrench Dual 6" Wiped Film Evaporator
Brand: Beaker & Wrench
SKU: BW-6WFE-D
Price: 390000.0 USD
Availability: InStock

Description

Beaker & Wrench Dual 6" Wiped Film Evaporator

The Beaker & Wrench Dual 6" Wiped Film Evaporator is a turnkey evaporation system designed to simplify large-scale cannabis oil distillation while delivering consistent productivity, purity, and process control. The fully functional system is designed to minimize setup requirements and provide an integrated solution for demanding production workflows.

This automated Dual 6" Wiped-Film Evaporation Turn-Key System combines precision temperature control, continuous feed and flow management, high-performance vacuum capability, and advanced cooling technology. The integrated system helps reduce user-dependent process variation while supporting controlled and repeatable evaporation conditions.

The system features an 8-channel UL-Listed PID Temperature Controller, 40L feed tank, 36 CFM rotary vane vacuum pump, -90°C immersion probe, inlet and outlet gear pumps, and a single NEMA 14-50 single-phase 240V electrical connection. The evaporator provides a 0.25m² evaporative area and is CE certified for applicable equipment requirements.

Dual 6" Wiped Film 40L Feed Tank 36 CFM Vacuum Pump -90°C Cooling

Precision Temperature Control: 8-channel UL-Listed PID controller — supports accurate and consistent process temperature management.

Continuous Feed System: 40L feed tank with inlet and outlet gear pumps — supports continuous material flow and reduced downtime.

Integrated Vacuum & Cooling: 36 CFM vacuum pump and -90°C immersion probe — provides key process infrastructure without requiring dry ice for cooling.

Why buy from USA Lab

Expert Support
Engineers & technicians on staff.

Quality First
Tested and trusted products.

Fast Fulfillment
Nationwide 1-2 day shipping.

Warranty & Parts
US-based service & spares.

Why this Beaker & Wrench Dual 6" Wiped Film Evaporator?

Turnkey operation — arrives as a fully functional system designed to simplify installation and reduce additional setup requirements.
Precision process control — 8-channel UL-Listed PID temperature control supports consistent operating conditions across the system.
Continuous feed capability — 40L feed tank and inlet/outlet gear pumps support controlled material flow and continuous operation.
Integrated vacuum and cooling — 36 CFM rotary vane vacuum pump and -90°C immersion probe provide essential process support without dry ice cooling.
Production-focused design — dual 6" wiped-film evaporation, 0.25m² evaporative area, CE certification, and a single 240V connection create an integrated production solution.

Talk to an expert

Get product guidance, application support, system specifications, and purchasing assistance for your wiped-film evaporation workflow.

Call 734-855-4890

Technical Specifications

Specification	Details
Product Name	Beaker & Wrench Dual 6" Wiped Film Evaporator
Evaporator Type	Dual 6" Wiped-Film Evaporator Turn-Key System
Evaporative Area	0.25 m² Evaporative Area
Temperature Control	8-channel UL-Listed PID Temperature Controller
Feed Tank Capacity	40 L
Vacuum Pump	36 CFM Rotary Vane Vacuum Pump
Cooling System	-90°C Immersion Probe
Flow Control	Inlet and Outlet Gear Pumps
Flow Operation	Continuous Flow
Power Requirement	One NEMA 14-50 Single-Phase 240V Plug
Dimensions (W × D × H)	75" W × 30" D × 86" H
Reduced Height	80" H to fit through doors
Certification	CE Certified
System Type	Turn-Key Evaporation System
Installation	Plug-and-Play Design
Primary Application	Large-Scale Cannabis Oil Distillation
Temperature Control Function	Precise and Consistent Process Management
Cooling Benefit	Eliminates the Need for Dry Ice
Lead Time	0-4 Weeks

Popular Industries & Use Cases

Botanical Extraction Pharmaceutical Chemical Sciences Academic & Research

Business Solutions & Procurement

Programs & Terms

Exclusive options for businesses and academics.

Apply for Net Terms Academic Discount

Documentation & Compliance

Keep purchasing streamlined and compliant.

Request a Quote Tax Exemption

Custom Solutions

Tailored equipment and integration help.

Custom Request Consulting

Talk to Sales

We’ll help spec the right equipment for your laboratory or production workflow.

Call 734-855-4890 Email Sales/Support

FAQ

What is included with the Beaker & Wrench Dual 6" Wiped Film Evaporator?

The turnkey system includes an integrated Dual 6" wiped-film evaporation system with an 8-channel UL-Listed PID temperature controller, 40L feed tank, 36 CFM rotary vane vacuum pump, -90°C immersion probe, inlet and outlet gear pumps, and associated system infrastructure.

What are the power requirements for the Beaker & Wrench Dual 6" Wiped Film Evaporator?

The system operates from one NEMA 14-50 single-phase 240V plug, simplifying the electrical connection requirements for the turnkey system.

Does the cooling system require dry ice?

No. The system uses a -90°C immersion probe, which is designed to eliminate the need for dry ice during operation.

What is the lead time for the Beaker & Wrench Dual 6" Wiped Film Evaporator?

The listed lead time is 0-4 weeks. Please contact USA Lab for current availability and delivery information before ordering.

Important Shipping Notice!

DISCLAIMER:

Large equipment systems may require specialized freight handling, crating, and delivery coordination. Please verify site access, electrical requirements, available space, and installation conditions before purchase.

For current freight requirements, lead time, delivery arrangements, or other shipping questions, please contact USA Lab before ordering.

Need Support?

We’ll get you answers fast.

Call 734-855-4890

Specifications

Brand:	Beaker & Wrench
Material:	316SS
Max Through Put:	Up to 7.0 L/hr
Average Throughput:	3.0-5.0 L/hr
Feed Rates:	Adjustable from 10mL to 10L/hr
Certifications:	CE
Lead Time:	1–3 Days
Warranty Term:	1 Year
