USA Lab 316L Sanitary Pressure Vessel w/ 4A Finish - ASME Certified

The USA Lab 316L Sanitary Pressure Vessel w/ 4A Finish - ASME is a fully certified, jacketed sanitary tank engineered for extraction, processing, mixing, and storage applications where purity, pressure control, and code compliance matter. Every vessel is built to ASME Boiler and Pressure Vessel Code, Section VIII, Division 1 (2025 Edition), stamped and registered with the National Board, and available in nine capacities from 25L to 800L to match your process scale.

All product-contact surfaces are constructed from 316L stainless steel with a 4A sanitary polish, while the outer jacket is built from 304 stainless steel for reliable heating and cooling control. The internal vessel is rated to 250 PSI (1.72 MPa) at 120°C with a minimum design metal temperature of -80°C, and the jacket is rated to 54.5 PSI (0.375 MPa), giving you a wide operating window for demanding thermal cycles.

This is a freight item — oversized/LTL shipping charges apply and will be confirmed prior to dispatch

500L, 600L and 800L include a Bolted flange with a 3" TC center

ASME Section VIII, Div. 1 316L Wetted Surfaces 4A Sanitary Finish Jacketed 25L–800L

Construction: 316L stainless wetted surfaces with a 4A sanitary polish.

Pressure Rating: 250 PSI internal @ 120°C · 54.5 PSI jacket

Certification: ASME Sec. VIII Div. 1 — U-Stamp, National Board Registered

Why buy from USA Lab

Expert Support
Engineers & technicians on staff.

Quality First
Tested and trusted products.

Fast Fulfillment
Nationwide 1-2 day shipping.

Warranty & Parts
US-based service & spares.

Why this ASME pressure vessel?

Code compliance built in — ASME Section VIII, Div. 1 (2025 Edition) construction, U-Stamped and National Board registered.
Sanitary wetted path — 316L stainless with a 4A polish for easy cleaning and product purity.
Dialed-in thermal control — 304 stainless jacket rated to 54.5 PSI for heating and cooling.
Nine capacities — 25L, 50L, 100L, 200L, 300L, 400L, 500L, 600L, and 800L to fit your line.

Talk to an expert

Get sizing help, SOP guidance, and integration tips for your line.

Call 734-855-4890

Technical Specifications

Model	Tank Volume (L/Gal)	Tank Pressure Rating (PSI)	Jacket Pressure Rating (PSI)	Material \| Polish	Center Connection	Top Connections	Angled Ports	Bottom Connection	Jacket Connection	Overall Dimensions (mm)	Overall Dimensions (in)	Weight
SPV-25L-ASME	25 L / 6.6 gal	250 PSI	N/A (no jacket)	316L \| 4A	6" TC	2x 1.5" TC \| 2x 1/2" MNPT	2x 2" TC	—	N/A	356L x 356W x 447H	14.02L x 14.02W x 17.6H	68.3 lb
SPV-50L-ASME	50 L / 13.2 gal	250 PSI	54.5 PSI	316L \| 4A	6" TC	4x 1.5" TC	2x 2" TC	6" Outlet	1.5" TC	406L x 406W x 1148.2H	15.98L x 15.98W x 45.2H	173.8 lb
SPV-100L-ASME	100 L / 26.4 gal	250 PSI	54.5 PSI	316L \| 4A	6" TC	4x 1.5" TC	2x 3" TC	6" Outlet	1.5" TC	506L x 506W x 1250H	19.92L x 19.92W x 49.21H	260.1 lb
SPV-200L-ASME	200 L / 52.8 gal	250 PSI	54.5 PSI	316L \| 4A	6" TC	4x 1.5" TC	2x 3" TC	6" Outlet	1.5" TC	556L x 556W x 1654H	21.89L x 21.89W x 65.12H	385.8 lb
SPV-300L-ASME	300 L / 79.3 gal	250 PSI	54.5 PSI	316L \| 4A	6" TC	4x 1.5" TC	2x 3" TC	6" Outlet	1.5" TC	706L x 706W x 1558H	27.8L x 27.8W x 61.34H	538.0 lb
SPV-400L-ASME	400 L / 105.7 gal	250 PSI	54.5 PSI	316L \| 4A	6" TC	4x 1.5" TC	2x 3" TC	6" Outlet	1.5" TC	756L x 756W x 1735H	29.76L x 29.76W x 68.31H	701.1 lb
SPV-500L-ASME	500 L / 132.1 gal	250 PSI	54.5 PSI	316L \| 4A	300# 10" Flange	4x 1.5" TC	2x 3" TC	6" Outlet	1.5" TC	856L x 856W x 1913H	33.7L x 33.7W x 75.31H	1071.5 lb
SPV-600L-ASME	600 L / 158.5 gal	250 PSI	54.5 PSI	316L \| 4A	300# 10" Flange	4x 1.5" TC	2x 3" TC	6" Outlet	1.5" TC	906L x 906W x 1942.7H	35.67L x 35.67W x 76.48H	1148.6 lb
SPV-800L-ASME	800 L / 211.3 gal	250 PSI	54.5 PSI	316L \| 4A	300# 10" Flange	4x 1.5" TC	2x 3" TC	6" Outlet	1.5" TC	958L x 958W x 2223.5H	37.72L x 37.72W x 87.54H	1567.6 lb

Popular Industries & Use Cases

Botanical Extraction Pharmaceutical Chemical Sciences Academic & Research

Business Solutions & Procurement

Programs & Terms

Exclusive options for businesses and academics.

Apply for Net Terms Academic Discount

Documentation & Compliance

Keep purchasing streamlined and compliant.

Request a Quote Tax Exemption

Custom Solutions

Tailored tanks, skids, and integration help.

Custom Request Consulting

Talk to Sales

We’ll help spec the right system for your throughput.

Call 734-855-4890 Email Sales/Support

FAQ

What sizes does this pressure vessel come in?

The USA Lab 316L Sanitary Pressure Vessel w/ 4A Finish - ASME is available in nine capacities — 25L, 50L, 100L, 200L, 300L, 400L, 500L, 600L, and 800L — so you can match the tank to your process volume.

Is this vessel ASME certified?

Yes. Every USA Lab 316L Sanitary Pressure Vessel w/ 4A Finish - ASME is built to ASME Boiler and Pressure Vessel Code, Section VIII, Division 1 (2025 Edition), U-Stamped, and registered with the National Board, with a Manufacturer’s Data Report (Form U-1) provided per unit.

What does the 4A sanitary finish mean?

On the USA Lab 316L Sanitary Pressure Vessel w/ 4A Finish - ASME, all product-contact surfaces are 316L stainless finished to a 4A polish, giving you a smooth, easy-to-clean wetted path suitable for sanitary processing.

Does it include a heating/cooling jacket?

All sizes 50L and above of the USA Lab 316L Sanitary Pressure Vessel w/ 4A Finish - ASME include a 304 stainless steel jacket rated to 54.5 PSI for heating and cooling; the 25L model is single-walled.
