Name: Edwards RV8 5.9 CFM Two-Stage Rotary Vane Vacuum Pump, 115/230V, 1-Ph, Factory Set 115V
Brand: Edwards
SKU: ED-A65401906
Price: 5750.0 USD
Availability: InStock

Description

Edwards RV8 5.9 CFM Two-Stage Rotary Vane Vacuum Pump, 115/230V 1-Ph | USA Lab

The Edwards RV8 is a compact, oil-sealed two-stage rotary vane vacuum pump designed to deliver reliable rough vacuum performance for demanding laboratory and industrial applications. With pumping speeds up to 5.9 CFM at 60 Hz and excellent ultimate pressure, the RV8 provides dependable vacuum generation for roughing, backing, and process applications.

The Edwards RV8 features a fast-acting automatic inlet valve for anti-suckback protection, helping safeguard connected equipment during shutdown. Its universal 115/230V single-phase motor is factory set to 115V, while the two-position gas ballast and mode selector provide flexibility when handling vapor-heavy loads.

Supplied with an initial charge of Ultragrade 19 oil, the RV8 is engineered for straightforward service and long-term operation. Polymer blades, self-aligning components, and serviceable shaft seals support practical maintenance and help reduce equipment downtime across demanding vacuum workflows.

Two-Stage Rotary Vane 5.9 CFM @ 60 Hz 1.5 × 10^-3 mbar Ultimate Gas Ballast GB I / II

Performance: Up to 5.9 CFM at 60 Hz — provides reliable roughing and backing performance for demanding vacuum applications.

Vapor Handling: Two-position gas ballast with mode selector — supports improved handling of vapor loads during wet processes.

Protection: Fast-acting automatic inlet valve — provides anti-suckback protection to help safeguard connected vacuum systems.

Why buy from USA Lab

Expert Support
Engineers & technicians on staff.

Quality First
Tested and trusted products.

Fast Fulfillment
Nationwide 1-2 day shipping.

Warranty & Parts
US-based service & spares.

Why the Edwards RV8?

High reliability — rugged two-stage rotary vane construction is designed for dependable long-term vacuum service.
Best-in-class protection — the fast-acting automatic inlet valve provides rapid anti-suckback protection during shutdown.
Optimized vapor handling — two-position gas ballast and a mode selector help match pump operation to vapor loads.
Easy maintenance — polymer blades, self-aligning components, and serviceable shaft seals simplify routine service.
Universal power — the 115/230V single-phase motor provides flexible installation, with the unit factory set to 115V.

Talk to an expert

Get sizing guidance, application support, and vacuum system recommendations for mass spectrometry, electron microscopy, coating, turbo backing, and other laboratory or industrial workflows.

Call 734-855-4890

Technical Specifications

Specification	Details
Model	Edwards RV8
Pump Type	Two-Stage Rotary Vane Vacuum Pump
Pump Classification	Wet / Oil-Sealed Rough Vacuum Pump
Peak Pumping Speed at 60 Hz	5.9 CFM
Peak Pumping Speed at 50 Hz	8.5 m³/h
Ultimate Pressure	1.5 × 10^-3 mbar
Ultimate Pressure GB II	6.0 × 10^-2 mbar
Water Vapour Tolerance	60 mbar (38 Torr)
Water Vapour Capacity — GB I	60 g/h
Water Vapour Capacity — GB II	220 g/h
Motor Rating 1-Phase	550 W at 60 Hz / 450 W at 50 Hz
Motor Rating 3-Phase	550 W at 60 Hz / 450 W at 50 Hz
Power Supply	115/230V, 1-Phase, 50/60 Hz
Gas Ballast	Two-position GB I / GB II with mode selector
Inlet Flange	NW25
Exhaust Flange	NW25
Weight	61.6 lb. (28 kg)
Oil Capacity	0.75 L
Oil Type	Ultragrade 19

Popular Industries & Use Cases

Botanical Extraction Pharmaceutical Chemical Sciences Academic & Research

Business Solutions & Procurement

Programs & Terms

Exclusive options for businesses and academics.

Apply for Net Terms Academic Discount

Documentation & Compliance

Keep purchasing streamlined and compliant.

Request a Quote Tax Exemption

Custom Solutions

Tailored equipment and integration help.

Custom Request Consulting

Talk to Sales

We’ll help spec the right vacuum equipment for your application.

Call 734-855-4890 Email Sales/Support

FAQ

What is the pumping speed of the Edwards RV8?

The Edwards RV8 delivers a peak pumping speed of 5.9 CFM at 60 Hz, with a listed pumping speed of 8.5 m³/h at 50 Hz, making it suitable for roughing, backing, and other demanding vacuum applications.

What type of vacuum pump is the Edwards RV8?

The Edwards RV8 is a two-stage, oil-sealed rotary vane vacuum pump designed for rough and medium vacuum applications in laboratory and industrial workflows.

Does the Edwards RV8 include oil?

Yes. The Edwards RV8 ships with an initial charge of Ultragrade 19 oil. The pump has an oil capacity of approximately 0.75 L.

What power does the Edwards RV8 require?

The Edwards RV8 uses a universal 115/230V single-phase motor operating at 50/60 Hz. This unit is factory set to 115V.
