The main purpose of the USA Lab Mechanical Cold Trap bath is to prevent vapors being produced by an experiment from entering then vacuum pump where it would condense and contaminate it. Cold traps can also cool surfaces or baffles to prevent oil vapors flowing from a pump into a chamber. The USA-CT40-UL model reaches a maximum temp of -40°F under vacuum and contains three traps for maximum efficiency and condensation of vapors.
|
USA-CT40-UL Specifications |
|
|
Temperature Controller |
Microprocessor Digital Controller |
|
Temperature Range |
Ambient to -60°C (-76° F) | (Low limit: -40°C | -40°F) |
|
Dimensions External LxWxH |
18.18" x 22.04" x 27.95" (465x560x710mm) |
|
Weight |
106lbs (48 kg) |
|
Material Internal |
Stainless Steel |
|
Material External |
Steel Plate with Powder Heating Coated |
|
Trap |
Openable Glass Trap ×3ea |
|
Power |
120V, 60Hz |
The USA-CT80-UL model reaches a maximum temp of -112°F under vacuum and contains three traps for maximum efficiency and condensation of vapors.
|
USA-CT80-UL Specifications |
|
|
Temp Controller |
Microprocessor Digital Controller |
|
Temp Range |
Ambient to -100°C (-148°F) | (Low limit: -80°C | -112°F) |
|
Dimensions External LxWxH |
19.88" x 24.41" x 29.52" (505x620x750mm) |
|
Weight |
167.551lbs (75 kg) |
|
Material Internal |
Stainless Steel |
|
Material External |
Steel Plate with Powder Heating Coated |
|
Trap |
Openable Glass Trap ×3ea |
|
Power |
110V, 60Hz |
For Technical Support, Questions, or Other Issues Please Email or Call Us!
